Machine Characteristics

● X,Y axis adopts 55mm rail design, Z axis adopts rectangular rail design. To improve the rigidity of the machine tool.
● The Z-axis dual-cylinder counterweight design reduces the inertia of the spindle box and improves the response speed to achieve high-precision machining.
● The three-axis screw rod is pre-stretched to reduce thermal extension and improve the accuracy of the machine tool.
● The spindle adopts BT40 and BT50 design, providing customers with multiple model options.
● The main shaft provides a belt main shaft, which is directly connected to the main shaft. ZF gear drive and full gear drive increase main shaft torque.
● The main structural parts are designed through finite element analysis to show the best structural stability and accuracy.
